- - - - - - -During the workshop you went through the OpenShift developer experience starting from software development using Quarkus and odo, moving on to automating build and deployment using Tekton pipelines and finally using GitOps for production deployments.
-Now it’s time to add another extremely important piece to the setup: enhancing application security in a containerized world. Using Red Hat Advanced Cluster Security for Kubernetes, of course!
-Install RHACS
-RHCAS Operator
-Install the Advanced Cluster Security for Kubernetes operator from the OperatorHub:
--
-
- Switch Update approval to
Manual
- - Apart from this use the default settings -
- Approve the installation when asked -
Red Hat recommends installing the Red Hat Advanced Cluster Security for Kubernetes Operator in the rhacs-operator namespace. This will happen by default..
-Installing the main component Central
- -You must install the ACS Central instance in its own project and not in the rhacs-operator and openshift-operator projects, or in any project in which you have installed the ACS Operator!
--
-
- Navigate to Operators → Installed Operators -
- Select the ACS operator -
- You should now be in the rhacs-operator project the Operator created, create a new OpenShift Project for the Central instance:
-
-
-
- Create a new project called stackrox (Red Hat recommends using stackrox as the project name.) by selecting Projects: Create project -
- - In the Operator view under Provided APIs on the tile Central click Create Instance -
- Switch to the YAML View. -
- Replace the YAML content with the following: -
apiVersion: platform.stackrox.io/v1alpha1
-kind: Central
-metadata:
- name: stackrox-central-services
- namespace: stackrox
-spec:
- monitoring:
- openshift:
- enabled: true
- central:
- notifierSecretsEncryption:
- enabled: false
- exposure:
- loadBalancer:
- enabled: false
- port: 443
- nodePort:
- enabled: false
- route:
- enabled: true
- telemetry:
- enabled: true
- db:
- isEnabled: Default
- persistence:
- persistentVolumeClaim:
- claimName: central-db
- resources:
- limits:
- cpu: 2
- memory: 6Gi
- requests:
- cpu: 500m
- memory: 1Gi
- persistence:
- persistentVolumeClaim:
- claimName: stackrox-db
- egress:
- connectivityPolicy: Online
- scannerV4:
- db:
- persistence:
- persistentVolumeClaim:
- claimName: scanner-v4-db
- indexer:
- scaling:
- autoScaling: Disabled
- maxReplicas: 2
- minReplicas: 1
- replicas: 1
- matcher:
- scaling:
- autoScaling: Disabled
- maxReplicas: 2
- minReplicas: 1
- replicas: 1
- scannerComponent: Default
- scanner:
- analyzer:
- scaling:
- autoScaling: Disabled
- maxReplicas: 2
- minReplicas: 1
- replicas: 1
--
-
- Click Create -
After the deployment has finished (Status Conditions: Deployed, Initialized in the Operator view on the Central tab), it can take some time until the application is completely up and running. One easy way to check the state, is to switch to the Developer console view on the upper left. Then make sure you are in the stackrox project and open the Topology map. You’ll see the three deployments of the Central instance:
-
-
- scanner -
- scanner-db -
- central -
- central-db -
Wait until all Pods have been scaled up properly.
-Verify the Installation
-Switch to the Administrator console view again. Now to check the installation of your Central instance, access the ACS Portal:
--
-
- Look up the central-htpasswd secret that was created to get the password -
If you access the details of your Central instance in the Operator page you’ll find the complete commandline using oc to retrieve the password from the secret under Admin Credentials Info. Just sayin… ;)
-
-
- Look up and access the route central which was also generated automatically. -
This will get you to the ACS Portal, accept the self-signed certificate and login as user admin with the password from the secret.
-Now you have a Central instance that provides the following services in an -RHACS setup:
--
-
-
-
The application management interface and services. It handles data persistence, API interactions, and user interface access. You can use the same Central instance to secure multiple OpenShift or Kubernetes clusters.
-
- -
-
Scanner, which is a vulnerability scanner for scanning container images. It analyzes all image layers for known vulnerabilities from the Common Vulnerabilities and Exposures (CVEs) list. Scanner also identifies vulnerabilities in packages installed by package managers and in dependencies for multiple programming languages.
-
-
To actually do and see anything you need to add a SecuredCluster (be it the same or another OpenShift cluster). For effect go to the ACS Portal, the Dashboard should by pretty empty, click on either of the Compliance link in the menu to the left, lots of zero’s and empty panels, too.
-This is because you don’t have a monitored and secured OpenShift cluster yet.
-Prepare to add Secured Clusters
-Now we’ll add your OpenShift cluster as Secured Cluster to ACS.
-First, you have to generate an init bundle which contains certificates and is used to authenticate a SecuredCluster to the Central instance, regardless if it’s the same cluster as the Central instance or a remote/other cluster.
-We are using the API to create the init bundle in this workshop, because if we use the Web Terminal we can’t upload and downloaded file to it. For the steps to create the init bundle in the ACS Portal see the appendix.
-Let’s create the init bundle using the ACS API on the commandline:
-Go to your Web Terminal (if it timed out just start it again), then paste, edit and execute the following lines:
--
-
- Set the ACS API endpoint, replace
<central_url>with the base URL of your ACS portal (without ‘https://’ e.g. central-stackrox.apps.cluster-cqtsh.cqtsh.example.com)
-
export ROX_ENDPOINT=<central_url>:443
--
-
- Set the admin password (same as for the portal, look up the secrets again) -
export PASSWORD=<password>
--
-
- Give the init bundle a name -
export DATA={\"name\":\"my-init-bundle\"}
--
-
- Finally run the
curlcommand against the API to create the init bundle using the variables set above
-
curl -k -o bundle.json -X POST -u "admin:$PASSWORD" -H "Content-Type: application/json" --data $DATA https://${ROX_ENDPOINT}/v1/cluster-init/init-bundles
--
-
- Convert it to the needed format -
cat bundle.json | jq -r '.kubectlBundle' > bundle64
-base64 -d bundle64 > kube-secrets.bundle
-You should now have these two files in your Web Terminal session: bundle.json and kube-secrets.bundle.
The init bundle needs to be applied to all OpenShift clusters you want to secure and monitor.
- -As said, you can create an init bundle in the ACS Portal, download it and apply it from any terminal where you can run oc against your cluster. We used the API method to show you how to use it and to enable you to use the Web Terminal.
Prepare the Secured Cluster
-For this workshop we run Central and SecuredCluster on one OpenShift cluster. E.g. we monitor and secure the same cluster the central services live on.
-Apply the init bundle
-Again in the web terminal:
--
-
- Run
oc create -f kube-secrets.bundle -n stackroxpointing to the init bundle you downloaded from the Central instance or created via the API as above.
- - This will create a number of secrets, the output should be: -
secret/collector-tls created
-secret/sensor-tls created
-secret/admission-control-tls created
-Add the Cluster as SecuredCluster to ACS Central
-You are ready to install the SecuredClusters instance, this will deploy the secured cluster services:
--
-
- In the OpenShift Web Console go to the ACS Operator in Operators->Installed Operators -
- Using the Operator create an instance of the Secured Cluster type in the Project you created (should be stackrox) -
- If you are in the YAML view switch to the Form view -
- Change the Cluster Name for the cluster if you want, it’ll appear under this name in the ACS Portal -
- And most importantly for Central Endpoint enter the address and port number of your Central instance, this is the same as the ACS Portal.
-
-
-
- If your ACS Portal is available at
https://central-stackrox.apps.<DOMAIN>the endpoint iscentral-stackrox.apps.<DOMAIN>:443.
-
- - If your ACS Portal is available at
- Under Admission Control Settings make sure
-
-
-
- listenOnCreates, listenOnUpdates and ListenOnEvents is enabled -
- Set Contact Image Scanners to ScanIfMissing -
- - Click Create -
Now go to your ACS Portal again, after a couple of minutes you should see your secured cluster under Platform Configuration->Clusters. Wait until all Cluster Status indicators become green.
-Configure Quay Integrations in ACS
-Create an integration to scan the Quay registry
-To enable scanning of images in your Quay registry, you’ll have to configure an Integration with valid credentials, so this is what you’ll do.
-Now, create a new Integration:
--
-
- Access the RHACS Portal and configure the already existing integrations of type Generic Docker Registry. -
- Go to Platform Configuration -> Integrations -> Generic Docker Registry. -
- Click the New integration button -
- Integration name: Quay local -
- Endpoint:
https://quay-quay-quay.apps.<DOMAIN>(replace domain if required)
- - Username: quayadmin -
- Password: quayadmin -
- Press the Test button to validate the connection and press Save when the test is successful. -
